Key Component Brands
| Drawing Module | HIWIN KK Module (Taiwan) | High rigidity & precision |
Motion Control Core | Mitsubishi PLC FX3U (Japan) |
| Temperature Control Core | Omron PID Auto-tuning Controller |
| HMI (Human-Machine Interface) | Weintek 10-inch Full-color Touch Panel |
| Drive Motor | Delta AC Servo Motor |
| Actuators & Valves | Full SMC Pneumatic Cylinders & Solenoid Valves (Japan) |
| Simultaneous Processing | 3 products |
设备参数
| Parameter | Value |
工作电压/功率 | AC 220V, 800W |
| 输入气源 | 压缩空气 Compressed air 0.5~1Mpa |
| 拉拔控制精度 | ±0.01 mm (linear), ±0.01 mm/s (speed) |
| 拉拔速度范围 | 0-200 mm/s |
| 模具温度 | 0-350°C (±2°C) |
| 同时拉伸产品数 | 3 products |
| 模组拉拔行程 | 0-450 mm |
| 可存储工艺参数 | 20个 |
